ALFZ-D Hydraulic-opening Stage Cementer manufacturer from China Baoji Allipower Equipment Co., Ltd

Payment Terms:	T/T
Place of Origin:	Shaanxi, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Air

Packing: Transport and storage frame...

Production Capacity: 20

Delivery Date: in 1-2 month(s) after recei...

With Max.OD 170mm, overall length for 1080mm

The ALFZ-D hydraulic-opening stage cementer features inner closing structure,opening by differential pressure. The closing plug drives the closing sleevedown and then shuts off circulating ports.

Features

1.Opening pressure can be adjusted and it is not affected by the hole angle or mudproperties for operation.

2. Thepressure-relief design prevents fluid trapping and compression during theclosing phase of the tool's operation.

3. TheI.D. of upper/lower sub is the same as that of casing, but smaller than that ofclosing sleeve, which can minimize chances of damages to the closingsleeve.

4. Theinner seats are made of an easily drillable butyronitrile rubber/aluminummaterial. Both the opening and closing seats lock against rotation for easydrillout.

Property Parameters

Specifications	φ139.7mm	φ177.8mm	φ244.5mm
Max. O.D. (mm)	170	208	283
Drill-out I.D. (mm)	122	155	220
Overall Length (mm)	1082	1182	1222
Rated Load (mm)	140	170	210
Sealing Capacity (MPa)	25	25	25
Opening Pressure (MPa)	18	18	18
Opening Force (KN)	85	136	278
Closing Pressure (MPa)	5	5	5
Closing Force (KN)	60	97	199
Lower Sliding Sleeve I.D. (mm)	85	115	176
Upper Sliding Sleeve I.D. (mm)	95	125	197
